DAIKIN Split System Heat Pump, Series: DZ16SA, 208 - 230 VAC, 18.9 A Minimum Circuit, 1/4 hp, 60 Hz, 1 -Phase, 36000 Btu/hr Cooling/Heating BTU, 16 SEER, HSPF: 9.5, 7/8 in Sweat Suction, 3/8 in Sweat Liquid Valve Connection, R-410A Refrigerant, 30 A Fuse, 3 ton, 72 dBA, 1 -Stage, Galvanized Steel, Powder-Painted, Nickel Gray, 40 in H x 35-1/2 in W x 35-1/2 in D
| Amperage Rating | : | 18.9 A Minimum Circuit |
| BTU Rating | : | 36000 Btu/hr Cooling/Heating |
| Color | : | Nickel Gray |
| Connection Type | : | 7/8 in Sweat Suction, 3/8 in Sweat Liquid Valve |
| Dimensions | : | 40 in H x 35-1/2 in W x 35-1/2 in D |
| Finish | : | Powder-Painted |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 30 A |
| HP Rating | : | 1/4 hp |
| HSPF Rating | : | 9.5 |
| Material | : | Galvanized Steel |
| Number of Stages | : | 1 |
| Phase | : | 1 |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 16 |
| Sound Level | : | 72 dBA |
| Tonnage | : | 3 ton |
| Voltage Rating | : | 208 - 230 VAC |
- Base feature set
- High-efficiency Copeland scroll compressor
- Advanced Copeland CoreSense technology
- High density foam compressor sound blanket
- Time delay technology to ensure quiet reliable defrost
- Factory installed bi-flow liquid line filter drier, suction line accumulator, compressor crankcase heater, high-capacity muffler
- High and low pressure switch
- Service valves with sweat connections and easy access to gauge ports
- Copper tube/enhanced aluminum fin coil
- Fully charged for 15 ft of tubing length
- Grille-style sound control top design cabinet
- Custom nickel gray powder paint finish
- 500 hr salt spray tested
- Wire fan discharge grille
- Steel louver coil guard
- Rust-resistant screws
- Top and side maintenance access
- Single-panel access to controls with space provided for field installed accessories
- 14.1 A-rated load, 72.2 A locked rotor compressor, 1.3 A full load condenser fan motor
- 1/2 in or 3/4 in electrical conduit
