Danfoss Maneurop Reciprocating Compressor, Series: MTZ, MTZ44HJ4AVE Model, 1-3/4 in Rotalock Suction Line, 1-1/4 in Rotalock Discharge Line, 7.8 cu-ft/min, 380 - 400/460 VAC, 4 hp, R-134A, R-404A, R-407A, R-407C, R-407F, R-507A Refrigerant, 2900 rev/min at 50 Hz Speed, Polyolester Compressor Oil, Blue, 16.34 in H x 11.34 in Dia
| CFM Rating | : | 7.8 cu-ft/min |
| Color | : | Blue |
| Compressor Oil | : | Polyolester |
| Dimensions | : | 16.34 in H x 11.34 in Dia |
| Discharge Line Size | : | 1-1/4 in Rotalock |
| Model | : | MTZ44HJ4AVE |
| Power Rating | : | 4 hp |
| Refrigerant Type | : | R-134A, R-404A, R-407A, R-407C, R-407F, R-507A |
| Speed Rating | : | 2900 rev/min at 50 Hz |
| Suction Line Size | : | 1-3/4 in Rotalock |
| Voltage Rating | : | 380 - 400/460 VAC |
- Design version
- Fixed speed control
- 7/8 in ODF suction with supplied sleeve, 3/4 in ODF discharge with supplied sleeve
- Threaded oil sight glass, 3/8 in flare SAE oil equalization
- Schrader LP gauge port
- Two-cylinders
- 76.2 cu-cm/rev swept volume
- 1.8 L oil charge
- 25 bars low side/30 bars high side maximum system test pressure, 30 bars maximum differential test pressure
- 5 kg refrigerant charge limit
- 42 A locked rotor, 9.5 A maximum continuous
- Internal overload motor protection, high efficiency circular valve design and high torque motors provide for a quality installation
- IP55 (with cable gland) Protection class
- 15 nm mounting torque
- 266 mm H suction x 75 mm H discharge
- 3.8 ohm winding-resistance (+/- 7% at 20 deg C)
- Spade power connection
