Equipped with material data and system diagnostics, the Reactor E-20 proportioner provides total control for spraying foam insulation. Advanced features provide longer equipment life, more uptime for your spray day and the overall GRACO® reliability and durability you've come to expect.
GRACO® E-20 Reactor and Proportioner Package, 230 V, Amperage Rating: 48 A, 50/60 Hz Frequency, Phase: 1, HP Rating: 8.05 hp, Heater Wattage: 6000 W, Maximum Fluid Working Pressure: 2000 psi, Maximum Fluid Temperature: 190 deg F, Output per Cycle: 0.0104 gal, Air Flow Rate: 20 lb/min, Fluid Inlet Size: 3/4 in, 50, 10 ft Hose Length, Wetted Materials: Aluminum, Brass, Carbide, Chrome, Chemically-Resistant O-Rings, PTFE, Stainless Steel, UHMWPE, Zinc-Plated Carbon Steel, 80 dB Sound Level, 31 in Width, 46 in Height, 33 in Depth
| Air Flow Rate | : | 20 lb/min |
| Amperage Rating | : | 48 A |
| Depth | : | 33 in |
| Fluid Inlet Size | : | 3/4 in |
| Frequency Rating | : | 50/60 Hz |
| HP Rating | : | 8.05 hp |
| Heater Wattage | : | 6000 W |
| Height | : | 46 in |
| Hose Length | : | 50, 10 ft |
| Maximum Fluid Temperature | : | 190 deg F |
| Maximum Fluid Working Pressure | : | 2000 psi |
| Output per Cycle | : | 0.0104 gal |
| Phase | : | 1 |
| Sound Level | : | 80 dB |
| Voltage Rating | : | 230 V |
| Wetted Materials | : | Aluminum, Brass, Carbide, Chrome, Chemically-Resistant O-Rings, PTFE, Stainless Steel, UHMWPE, Zinc-Plated Carbon Steel |
| Width | : | 31 in |
- Powerful hybrid heaters for better temperature control
- Circulation valves with longer-lasting seals
- Longer-lasting modular heater control boards that minimize downtime
- Hose heat transformer that doesn't require tap settings
- Easy-to maneuver
- Quick knockdown lower pumps for easy maintenance
- Digital heat and pressure controls
