Re-Verber-Ray® DX3L-40-100-NG ERP_072595
Re-Verber-Ray® DX3L Series DX3L-40-100-NG Infrared Tube Heater, 100000 Btu/hr BTU, Flare MFPT Connection
- Manufacturer: Detroit Radiant Products Company
- Brand Name: Re-Verber-Ray®
- Part Number: ERP_072595
- MPN: DX3L-40-100-NG
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
Packed with quality features, the DX3L represents the highest in quality, 1-stage, low intensity tube heaters. Performance is enhanced through the use of a specially designed stainless steel burner and black-coated titanium stabilized and/or aluminized-coated steel radiant tube exchangers. The DX3L series offers superior low intensity heat, performance and longevity.
Re-Verber-Ray® DX3L Infrared Tube Heater, 120 VAC, 1.1 A, 60 Hz Frequency, 1 Phase, 100000 Btu/hr, Vent, Flare MFPT Connection, Silicon Carbide Ignition, Natural Gas, 5 to 14 in-WC Pressure, 13 to 23 ft Mounting Height, Black, 1030 deg F, 41 ft 1 in L Dimensions, Domestic
| Amperage Rating | : | 1.1 A |
| BTU Rating | : | 100000 Btu/hr |
| Color | : | Black |
| Connection Type | : | Flare MFPT |
| Dimensions | : | 41 ft 1 in L |
| Domestic/Import | : | Domestic |
| Frequency Rating | : | 60 Hz |
| Gas Type | : | Natural Gas |
| Ignition Type | : | Silicon Carbide |
| Mounting Height | : | 13 to 23 ft |
| Phase | : | 1 |
| Pressure Rating | : | 5 to 14 in-WC |
| Temperature Rating | : | 1030 deg F |
| Vent, Ducted or Ductless | : | Vent |
| Voltage Rating | : | 120 VAC |
- High-quality construction materials enhance performance and equipment longevity
- 100% aluminized steel tubes with 0.95 emissive coating
- Pre and post-purge controls
- Self-diagnostic LED, microprocessor based circuitry
- Independent control air gas compartments with tool-free access
- Fitted ABS plastic air intake collar
- Reliable hot surface ignition
- 24 V controls and power cord standard
- Made in the USA
